Quartzlock E10-X - Horloge rubidium labo

Low cost, compact desktop rubidium frequency standard.

The Quartzlock E10-X Desktop Rubidium Frequency Reference, is a miniature Atomic Clock with 10MHz sine-wave 50 Ohm output.

Operating from an external 12Vdc, this miniature enclosure, only 103 x 55 x 122mm has all the performance needed for on-site calibrations, referencing and portable transfer standard applications. Quartzlock's SMAC (sub miniature atomic clock) technology far outperforms chip scale atomic clock devices with poor AVAR & phase noise.

The E10-X benefits from simple operation just connect output BNC connector to device under reference.

The E10-X is hand held, with

The power consumption is 6W at 12V dc / 500mA after 3min warm time.

No antenna is required or view of sky as the E10-X is a completely independent atomic reference.

Applications include: remote site cellular BTS transmitter and satellite communications ground station frequency referencing for calibration. Field service, low noise (remote from supply line hum & noise) development and short production test use. Noise elimination in referencing for signal sources, spectrum analysers, network analysers, subject to lab noise problems.

Features

• No drift
• High stability
• Compact light weight design
• Stability 8 x 10-11/s

Applications

• Frequency calibration
• Telecom network synchronisation
• Broadcast
• Aviation
• Nautical
• Precision test and measurement enviroments
• Cellular wireless base stations

Benefits

• Cost effective
• High performance reference
• Precise Frequency Reference
• SMAC technology
