Tabor 8571A - Générateur pulses 50 MHZ 1 voie

Générateur de Pulse TABOR 8571A

50MHz Single-Channel Pulse Generator

Model PM8571A is very high performance, single channel pulse/pattern generator that stretch normal pulse generators` spec to the limit, becoming by far the most advanced pulse waveform generator available in the market. In addition to its high performance pulse features, the new PM8571A generate a complete array of standard, arbitrary and sequenced waveforms which are necessities in today`s laboratories.

• 50MHz Single Channel Pulse / Pattern generator
• 100MHz Function Generator for standard waveforms
• 300MS/s, 16Bit Arbitrary Waveform / Sequence Generator
• 10ps pulse resolution with 4ns transition time
• 32Vpp into open circuit with programmable impedance
• 16-Bit Digital Pattern Generator with programmable level
• AM, FM, FSK, ASK, PSK, PWM and sweep
• Powerful sequence generator links and loops segments in user-defined fashion
• Stores up to 10 different sequence tables
• High resolution 3.8” User Friendly color LCD display
• Ethernet, USB and GPIB interfaces
• Waveforms transfer and storage through USB/CD/DVD
• “Drop-in” Emulators for: Fluke 80/1, HP8116, HP8112, HP8160, HP8165, Tabor 8500, Tabor 8550/1
